Select	AKS Part Number	Status	Spice model	Package	VDS(V)	Vgs(V)	ID(A)	Vth_Typ(V)	RDSon_Typ @10V(mΩ)	RDSon_Max @10V(mΩ)	CISS_Typ (pF)	COSS_Typ (pF)	CRSS_Typ (pF)	QG_Typ (nC)
Select
	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter
	AKS65N3K6FM Datasheets Marking POD 1 POD 2 Tape&reel 1 Tape&reel 2	MP	-	TO-220F	650	±30	11	3.5	300	360	841	45.1	2.8	23.3
	AK3S65N2K9PMF Datasheets Marking POD Tape&reel	MP	-	TO-220	650	30	15	3.6	260	290	647	20	7	22
	AK3S65N2K9FMF Datasheets Marking POD Tape&reel	MP	-	TO-220F	650	30	15	3.6	260	290	647	20	7	22
	AK3S65N3K6KMF Datasheets Marking POD Tape&reel	MP	-	TO-252	650	30	12.5	3.4	302	360	530	15	5.5	20
	AK3S65N3K6FMF Datasheets Marking POD Tape&reel	MP	-	TO-220F	650	30	12.5	3.4	302	360	530	15	5.5	20
	AK3S65N6K0FMF Datasheets Marking POD Tape&reel	NEW	-	TO-220F	650	30	8	3.5	510	600	338	13	5.5	14
	AK3S65N6K0KMF Datasheets Marking POD Tape&reel	NEW	-	TO-252	650	30	8	3.5	510	600	338	13	5.5	14
	AKS65N1M4KM	MP	-	TO-252	650	30	3	3.5	1250	1400	225	44.5	0.5	7.7
	AKS65N1M2KM	MP	-	TO-252	650	30	4	3.5	1000	1200	265	30.4	0.5	12.2
	AKS65N6K0KM	MP	-	TO-252	650	30	8	3.5	505	600	515	43.8	0.7	15
	AKS65N6K0FM	MP	-	TO-220F	650	30	8	3.5	505	600	515	43.8	0.7	15
	AKS65N3K6PM	MP	-	TO-220	650	30	11	3.5	280	360	841	45.1	2.8	23.3
	AKS65N3K6FAM	MP	-	TO-220NF	650	30	11	3.5	280	360	841	45.1	2.8	23.3
	AKS65N3K6LM	MP	-	PDFN8*8	650	30	11	3.5	280	360	841	45.1	2.8	23.3
	AKS70N6K0KM	MP	-	TO-252	700	30	8	3.5	540	600	515	43.8	0.7	15
	AK2S65N590WMF AK2S65N590WMF	MP	-	TO-247-3L	650	30	50	3.5	48	59	5270	122	8	133
	AK2S65N3K6KM AK2S65N3K6KM	MP	-	TO-252	650	30	11	3.5	310	360	600	20	5.8	22
	AKS65N410WMF-A	MP	-	TO-247	650	30	62	3.8	34	41	6715	245	1.64	172
