Select	AKS Part Number	Status	Spice model	Package	Cfg.	VDS(V)	Vgs(V)	ID(A)	Vth_Typ(V)	RDSon_Typ @10V(mΩ)	RDSon_Max @10V(mΩ)	RDSon_Typ @4.5V(mΩ)	RDSon_Max @4.5V(mΩ)	CISS_Typ (pF)	COSS_Typ (pF)	CRSS_Typ (pF)	QG_Typ (nC)
Select
	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter
	AKG10N042PM Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	TO-220	N	100	20	120	3.0	3.7	4.2	-	-	4270	1280	63	66.1
	AKG10N220KL AKG10N220KL	MP	-	TO-252	N	100	20	35	2.0	18	22	25	30	973	238	17.5	16.7
	AKG100N15G	MP	-	PDFN5*6-8L	N	100	20	46	2.0	12.5	15	16.5	22.5	1441	391	15	22
	AKG100N15K	MP	-	TO-252	N	100	20	55	2.0	12.5	15	15.6	22.5	1441	391	15	22
	AKG10N046GL	MP	-	PDFN5*6-8L	N	100	20	85	1.9	3.8	4.6	5.2	6.4	4590	1060	38.4	79
	AKG10N042DM AKG10N042DM	MP	-	TO-263	N	100	20	120	3.0	3.7	4.2	-	-	6070	1320	65	88
	AKG100N042P	MP	-	TO-220	N	100	20	175	3.3	3.6	4.2	-	-	5509	651	31	80.8
	AKG100N042D	MP	-	TO-263	N	100	20	175	3.3	3.6	4.2	-	-	5509	651	31	80.8
	AKG10N038GL Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	PDFN5*6	N	100	20	104	2.0	3.1	3.8	4.2	4.9	5980	1270	31.5	100
	AKG100N10G Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	PDFN5*6	N	100	±20	55	2.0	8	10	10.5	13.5	2198	508	23	35
	AKG10N100PM Datasheets Marking POD1 POD2 Tape&reel1 Tape&reel2	MP	-	TO-220	N	100	20	70	3.0	8.5	10	-	-	1611	549	30	26.3
	AKG10N100DM AKG10N100DM	MP	-	TO-263	N	100	20	70	3.0	8.5	10	-	-	1611	549	30	26.3
	AKG10N130KL AKG10N130KL	MP	-	TO-252	N	100	20	53	2.0	10	13	14	17	1565	390	25	27
	AKG10N130QL	MP	-	PDFN3.3*3.3	N	100	20	22	2.0	10	13	14	17	1565	390	25	27
	AKG10N130GL	MP	-	PDFN5*6	N	100	20	36	2.0	10	13	14	17	1565	390	25	27
	AKG10N038DM Datasheets Marking POD Tape&reel	MP	-	TO-263-3L	N	100	20	185	2.7	3.3	3.8	-	-	8845	1680	57	128
	AKG10N100KL AKG10N100KL	MP	-	TO-252	N	100	20	61	2.0	8	10	11	14	2030	495	27	30
