便携式储能电源在户外活动、应急备灾和家庭储能等多个场景中发挥着重要作用，提供了可靠、环保和高效的电力支持，瑶芯为便携式储能电源提供全套解决方案，包括高压IGBT，超结MOS，SiC MOS，低压SGT MOS等。

框图

共创智能与可持续的未来

沪ICP备 2020036924号-1 沪公网安备31011502402881号
 隐私政策

产品中心: 硅功率器件; 碳化硅功率器件; MEMS传感器; 信号链芯片

产品应用: 汽车; 绿色能源; 通信; 高性能计算; 工业; 智能生活

质量管理: 质量方针; 质量体系认证证书; 全面质量管理

关于瑶芯: 企业简介; 企业文化; ESG; 企业视频

联系我们: 联系方式; 销售网络; 留言反馈

Select	AKS Part Number	Status	Spice model	Package	Cfg.	VDS(V)	Vgs(V)	ID(A)	Vth_Typ(V)	RDSon_Typ @10V(mΩ)	RDSon_Max @10V(mΩ)	RDSon_Typ @4.5V(mΩ)	RDSon_Max @4.5V(mΩ)	CISS_Typ (pF)	COSS_Typ (pF)	CRSS_Typ (pF)	QG_Typ (nC)
Select
	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter
	AKG10N042PM Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	TO-220	N	100	20	120	3.0	3.7	4.2	-	-	4270	1280	63	66.1
	AKG10N220KL AKG10N220KL	MP	-	TO-252	N	100	20	35	2.0	18	22	25	30	973	238	17.5	16.7
	AKG100N15G	MP	-	PDFN5*6-8L	N	100	20	46	2.0	12.5	15	16.5	22.5	1441	391	15	22
	AKG100N15K	MP	-	TO-252	N	100	20	55	2.0	12.5	15	15.6	22.5	1441	391	15	22
	AKG10N046GL	MP	-	PDFN5*6-8L	N	100	20	85	1.9	3.8	4.6	5.2	6.4	4590	1060	38.4	79
	AKG10N042DM AKG10N042DM	MP	-	TO-263	N	100	20	120	3.0	3.7	4.2	-	-	6070	1320	65	88
	AKG100N042P	MP	-	TO-220	N	100	20	175	3.3	3.6	4.2	-	-	5509	651	31	80.8
	AKG100N042D	MP	-	TO-263	N	100	20	175	3.3	3.6	4.2	-	-	5509	651	31	80.8
	AKG10N038GL Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	PDFN5*6	N	100	20	104	2.0	3.1	3.8	4.2	4.9	5980	1270	31.5	100
	AKG100N10G Datasheets Marking POD 1 POD 2 POD 3 Tape&reel 1 Tape&reel 2 Tape&reel 3	MP	-	PDFN5*6	N	100	±20	55	2.0	8	10	10.5	13.5	2198	508	23	35
	AKG10N100PM Datasheets Marking POD1 POD2 Tape&reel1 Tape&reel2	MP	-	TO-220	N	100	20	70	3.0	8.5	10	-	-	1611	549	30	26.3
	AKG10N100DM AKG10N100DM	MP	-	TO-263	N	100	20	70	3.0	8.5	10	-	-	1611	549	30	26.3
	AKG10N130KL AKG10N130KL	MP	-	TO-252	N	100	20	53	2.0	10	13	14	17	1565	390	25	27
	AKG10N130QL	MP	-	PDFN3.3*3.3	N	100	20	22	2.0	10	13	14	17	1565	390	25	27
	AKG10N130GL	MP	-	PDFN5*6	N	100	20	36	2.0	10	13	14	17	1565	390	25	27
	AKG10N038DM Datasheets Marking POD Tape&reel	MP	-	TO-263-3L	N	100	20	185	2.7	3.3	3.8	-	-	8845	1680	57	128
	AKG10N100KL AKG10N100KL	MP	-	TO-252	N	100	20	61	2.0	8	10	11	14	2030	495	27	30
	AKG10N012TM-A Datasheets Marking POD Tape&reel	MP	-	TOLL	N	100	20	300	2.8	0.98	1.25	-	-	20760	4310	117	291

Select	AKS Part Number	Status	Spice model	Package	VDS(V)	Vgs(V)	ID(A)	Vth_Typ(V)	RDSon_Typ @10V(mΩ)	RDSon_Max @10V(mΩ)	CISS_Typ (pF)	COSS_Typ (pF)	CRSS_Typ (pF)	QG_Typ (nC)
Select
	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter	Filter
	AK3S60N290WMF Datasheets Marking POD Tape&reel	NEW	-	TO-247	600	30	80	4.0	26	29	4510	115	30	134
	AK3S60N580TMF Datasheets Marking POD Tape&reel	NEW	-	TOLL	600	30	50	3.8	45	58	2890	63	15	95
	AKS65N1K9PM Datasheets Marking POD 1 POD 2 Tape&reel	MP	-	TO-220	650	30	20	3.3	145	190	1670	83.1	0.8	44
	AK3S60N580PMF Datasheets Marking POD Tape&reel	MP	-	TO-220	600	30	50	3.8	45	58	2890	63	15	95
	AK3S60N580WMF Datasheets Marking POD Tape&reel	MP	-	TO-247	600	30	50	3.8	45	58	2890	63	15	95
	AK3S60N450WMF Datasheets Marking POD Tape&reel	NEW	-	TO-247	600	30	52	4.0	38	45	3580	78	21	117
	AK3S60N450PMF Datasheets Marking POD Tape&reel	MP	-	TO-220	600	30	52	4.0	38	45	3580	78	21	117
	AK3S60N380WMF Datasheets Marking POD Tape&reel	MP	-	TO-247	600	30	63	4.0	33	38	3975	90	33	136
	AK2S65N990WMF Datasheets Marking POD Tape&reel	MP	-	TO-247	650	30	38	4.1	75	99	2380	66	7	68
	AK3S60N1K8FMF Datasheets Marking POD Tape&reel	MP	-	TO-220F	600	30	11	4.0	140	180	1287	26	3	32
	AK3S60N380PMF Datasheets Marking POD Tape&reel	NEW	-	TO-220	600	30	63	4.0	33	38	3975	90	93	136
	AK3S60N450TMF Datasheets Marking POD Tape&reel	MP	-	TOLL	600	30	52	4.0	38	45	3580	78	21	117
	AKS60N300WMF AKS60N300WMF	MP	-	TO-247-3L	600	30	80	3.5	25	30	7699	3091	2.1	200.8
	AKS65N1K9DM	MP	-	TO-263	650	30	20	3.3	140	190	1670	83.1	0.8	44
	AKS65N1K9FM	MP	-	TO-220F	650	30	20	3.3	140	190	1670	83.1	0.8	44
	AKS65N1K9FAM	MP	-	TO-220NF	650	30	20	3.3	140	190	1670	83.1	0.8	44
	AKS65N410WMF	MP	-	TO-247-3L	650	30	62	4.0	34	41	6715	245	1.64	172
	AKS65N950WMF AKS65N950WMF	MP	-	TO-247	650	30	35	4.0	84	95	3375	76	8	90
	AKS65N1K9FMF Datasheets Marking POD Tape&reel	MP	-	TO-220F	650	30	20	3.8	136	190	1695	74	2	46
	AKS65N1K9LM	MP	-	PDFN8*8	650	30	30	3.3	140	190	1670	83.1	0.8	44
	AKS65N2M2KMF AKS65N2M2KMF	MP	-	TO-252	650	30	2	3.7	1800	2200	159	22	2.5	8.1
	AK3S60N220WMF AK3S60N220WMF	MP	-	TO-247	600	30	130	4.3	15.5	22	11165	173	20	278
	AK3S65N370WMF AK3S65N370WMF	MP	-	TO-247-3L	650	30	65	4.0	29	37	7185	103	16	160
	AK3S60N221WMF AK3S60N221WMF	MP	-	TO-247	600	30	100	4.3	18.5	22.1	9820	160	7	245
	AK3S60N680WMF AK3S60N680WMF	MP	-	TO-247	600	30	35	4.0	56	68	3240	60	3.5	83
	AK3S60N355TMF AK3S60N355TMF	MP	-	TOLL	600	30	63	4.0	32	35.5	3975	90	33	136
	AKS65N1K9PMF AKS65N1K9PMF	MP	-	TO-220	650	30	21	3.8	144	190	1695	74	2	46
	AK3S60N1K8FMF AK3S60N1K8FMF	MP	-	TO-220F	600	30	11	4.0	140	180	1287	26	3	32
